High-Precision Flicker-Free Dimming LED Constant Current Driver, Supports Buck / Boost / Buck-Boost Topologies And Multiple Dimming Modes

Hichips  Series LED Driver IC Datasheet Parameter English Translation

Hi7320

Type: DC-DC

DC Input Voltage: 6.5V~75V

Switching Frequency: 130kHz

Channel Count: N/A

Output Voltage: N/A

Output Current: 10A

Dimming Mode: PWM, Analog

Features: OTP (Over-Temperature Protection)

AC Input Voltage: N/A

Topology: Buck

Operating Temperature: -40℃~+125℃

Power MOSFET: External

Constant Current Accuracy: ±3%

Hi5010Q

Type: DC-DC

DC Input Voltage: 6.5V~75V

Switching Frequency: 130kHz

Channel Count: 1

Output Voltage: N/A

Output Current: 10A

Dimming Mode: PWM, Analog

Features: OVP (Over-Voltage Protection), OTP (Over-Temperature Protection)

AC Input Voltage: N/A

Topology: Buck-Boost

Operating Temperature: -40℃~+130℃

Power MOSFET: External

Constant Current Accuracy: ±3%

Hi7021

Type: DC-DC

DC Input Voltage: 6.5V~100V

Switching Frequency: 1MHz

Channel Count: 1

Output Voltage: N/A

Output Current: 1.5A

Dimming Mode: PWM

Features: OTP (Over-Temperature Protection)

AC Input Voltage: N/A

Topology: Buck

Operating Temperature: -40℃~+125℃

Power MOSFET: Internal

Constant Current Accuracy: ±3%

HI7301

Type: DC-DC

DC Input Voltage: 6.5V~75V

Switching Frequency: 130kHz~230kHz

Channel Count: 1

Output Voltage: N/A

Output Current: 1.5A

Dimming Mode: PWM, Analog

Features: OTP (Over-Temperature Protection)

AC Input Voltage: N/A

Topology: Buck

Operating Temperature: -40℃~+125℃

Power MOSFET: Internal

Constant Current Accuracy: ±3%

Hi7331

Type: DC-DC

DC Input Voltage: 6.5V~75V

Switching Frequency: 130kHz

Channel Count: 1

Output Voltage: N/A

Output Current: 1.5A

Dimming Mode: PWM, Analog

Features: OTP (Over-Temperature Protection)

AC Input Voltage: N/A

Topology: Buck

Operating Temperature: -40℃~+125℃

Power MOSFET: Internal

Constant Current Accuracy: ±3%

Hi7005s

Type: DC-DC

DC Input Voltage: 5V~40V

Switching Frequency: 1MHz

Channel Count: 1

Output Voltage: N/A

Output Current: 500mA

Dimming Mode: PWM

Features: OTP (Over-Temperature Protection)

AC Input Voltage: N/A

Topology: Buck

Operating Temperature: -40℃~+125℃

Power MOSFET: Internal

Constant Current Accuracy: ±3%

Hi9103B

Topology: Buck

Input Voltage Range: 8V~150V

Output Voltage Range: 5V~30V

Output Current: 1.5A

Switching Frequency: 150kHz

Operating Temperature: -40℃~+125℃

Synchronous Rectification: No

Output Channel Count: 1

Quiescent Current (Iq): 1mA

Power MOSFET: Internal

Output Type: Adjustable

Features: Light Load High Efficiency Mode, Cable Drop Compensation, Built-in LDO Regulator, Cycle-by-Cycle Current Limiting, Over-Current Protection, Adjustable Current Limit

Hi7200A

Type: DC-DC

DC Input Voltage: 6V~65V

Switching Frequency: 1MHz

Channel Count: N/A

Output Voltage: N/A

Output Current: 10A

Dimming Mode: PWM

Features: OTP (Over-Temperature Protection), LED Open Protection, SCP (Short-Circuit Protection)

AC Input Voltage: N/A

Topology: Buck

Operating Temperature: -40℃~+125℃

Power MOSFET: External

Constant Current Accuracy: ±3%

HI7321

Type: DC-DC

DC Input Voltage: 6.5V~75V

Switching Frequency: 130kHz

Channel Count: 1

Output Voltage: N/A

Output Current: 1.5A

Dimming Mode: PWM, Analog

Features: N/A

AC Input Voltage: N/A

Topology: Buck

Operating Temperature: -40℃~+125℃

Power MOSFET: Internal

Constant Current Accuracy: ±3%

Hi9102

Topology: Buck

Input Voltage Range: 8V~60V

Output Voltage Range: 5V~36V

Output Current: 3A

Switching Frequency: 150kHz

Operating Temperature: -40℃~+125℃

Synchronous Rectification: No

Output Channel Count: 1

Quiescent Current (Iq): N/A

Power MOSFET: Internal

Output Type: Adjustable

Features: Light Load High Efficiency Mode, Cable Drop Compensation, Built-in LDO Regulator, Cycle-by-Cycle Current Limiting, Over-Current Protection, Adjustable Current Limit

HI7300

Type: DC-DC

DC Input Voltage: 6.5V~75V

Switching Frequency: 130kHz / 230kHz

Channel Count: 1

Output Voltage: N/A

Output Current: 10A

Dimming Mode: PWM, Analog

Features: OTP (Over-Temperature Protection)

AC Input Voltage: N/A

Topology: Buck

Operating Temperature: -40℃~+125℃

Power MOSFET: External

Constant Current Accuracy: ±3%

HI15010

Type: Linear LED Driver

DC Input Voltage: 5V~80V

Switching Frequency: N/A

Channel Count: 1

Output Voltage: N/A

Output Current: 1A

Dimming Mode: PWM

Features: OVP (Over-Voltage Protection)

AC Input Voltage: N/A

Topology: Linear

Operating Temperature: -40℃~+125℃

Power MOSFET: Internal

Constant Current Accuracy: ±3%

Hi9100-DM

Topology: Buck

Input Voltage Range: 8V~150V

Output Voltage Range: 3V~36V

Output Current: 10A

Switching Frequency: 150kHz

Operating Temperature: -40℃~+125℃

Synchronous Rectification: No

Output Channel Count: 1

Quiescent Current (Iq): 1mA

Power MOSFET: External

Output Type: Adjustable

Features: Cable Drop Compensation, Built-in LDO Regulator, Cycle-by-Cycle Current Limiting, Over-Current Protection, Adjustable Current Limit

Hi7015

Type: DC-DC

DC Input Voltage: 4V~30V

Switching Frequency: 1MHz

Channel Count: 1

Output Voltage: N/A

Output Current: 500mA

Dimming Mode: PWM

Features: OTP (Over-Temperature Protection)

AC Input Voltage: N/A

Topology: Buck

Operating Temperature: -40℃~+125℃

Power MOSFET: Internal

Constant Current Accuracy: ±3%

Hi5001Q

Type: DC-DC

DC Input Voltage: 6.5V~75V

Switching Frequency: 130kHz

Channel Count: 1

Output Voltage: N/A

Output Current: 1.5A

Dimming Mode: PWM, Analog

Features: OVP (Over-Voltage Protection), OTP (Over-Temperature Protection)

AC Input Voltage: N/A

Topology: Buck-Boost

Operating Temperature: -40℃~+125℃

Power MOSFET: Internal

Constant Current Accuracy: ±3%

Hi7330

Type: DC-DC

DC Input Voltage: 6.5V~75V

Switching Frequency: 130kHz

Channel Count: N/A

Output Voltage: N/A

Output Current: 10A

Dimming Mode: PWM

Features: OTP (Over-Temperature Protection)

AC Input Voltage: N/A

Topology: Buck

Operating Temperature: -40℃~+125℃

Power MOSFET: External

Constant Current Accuracy: ±3%

Hi1506E

Type: Linear LED Driver

DC Input Voltage: 5V~80V

Switching Frequency: N/A

Channel Count: 1

Output Voltage: N/A

Output Current: 1A

Dimming Mode: PWM

Features: OVP (Over-Voltage Protection)

AC Input Voltage: N/A

Topology: Linear

Operating Temperature: -40℃~+125℃

Power MOSFET: Internal

Constant Current Accuracy: ±3%

Hi1503E

Type: Linear LED Driver

DC Input Voltage: 5V~80V

Switching Frequency: N/A

Channel Count: 1

Output Voltage: N/A

Output Current: 1A

Dimming Mode: PWM

Features: OVP (Over-Voltage Protection)

AC Input Voltage: N/A

Topology: Linear

Operating Temperature: -40℃~+125℃

Power MOSFET: Internal

Constant Current Accuracy: ±3%

Hi7020

Type: DC-DC

DC Input Voltage: 4.7V~80V

Switching Frequency: 1MHz

Channel Count: 1

Output Voltage: N/A

Output Current: 5A

Dimming Mode: PWM

Features: OTP (Over-Temperature Protection)

AC Input Voltage: N/A

Topology: Buck

Operating Temperature: -40℃~+125℃

Power MOSFET: External

Constant Current Accuracy: ±3%

HLD5050AL

Output Polarity: Positive

Input Voltage Rating: 50V

Fixed Output Voltage: 5V

Output Current: 250mA

PSRR: N/A

Dropout Voltage: 550mV @ 100mA

Quiescent Current (Iq): 2μA

Noise: N/A

Features: Short-Circuit Protection, Thermal Shutdown

Operating Temperature: -40℃~+125℃

Output Type: Fixed

Output Channel Count: 1

Hi6001

Type: DC-DC

DC Input Voltage: 2.7V~40V

Switching Frequency: 130kHz~1MHz

Channel Count: 1

Output Voltage: N/A

Output Current: 1A

Dimming Mode: PWM

Features: OVP (Over-Voltage Protection), OTP (Over-Temperature Protection)

AC Input Voltage: N/A

Topology: Boost

Operating Temperature: -40℃~+125℃

Power MOSFET: Internal

Constant Current Accuracy: ±3%

Hi7010

Type: DC-DC

DC Input Voltage: N/A

Switching Frequency: 1MHz

Channel Count: 1

Output Voltage: N/A

Output Current: 5A

Dimming Mode: PWM

Features: OTP (Over-Temperature Protection)

AC Input Voltage: N/A

Topology: Buck

Operating Temperature: -40℃~+125℃

Power MOSFET: External

Constant Current Accuracy: ±3%

HI9101

Topology: Buck

Input Voltage Range: 8V~150V

Output Voltage Range: 5V~36V

Output Current: 2A

Switching Frequency: 150kHz

Operating Temperature: -40℃~+125℃

Synchronous Rectification: No

Output Channel Count: 1

Quiescent Current (Iq): N/A

Power MOSFET: Internal

Output Type: Adjustable

Features: Light Load High Efficiency Mode, Cable Drop Compensation, Built-in LDO Regulator, Cycle-by-Cycle Current Limiting, Over-Current Protection, Adjustable Current Limit

Hi4322

Type: DC-DC

DC Input Voltage: 4V~100V

Switching Frequency: 1MHz

Channel Count: N/A

Output Voltage: N/A

Output Current: 1.5A

Dimming Mode: PWM

Features: OTP (Over-Temperature Protection)

AC Input Voltage: N/A

Topology: Buck

Operating Temperature: -40℃~+125℃

Power MOSFET: Internal

Constant Current Accuracy: ±3%

Hi1243E

Type: Linear LED Driver

DC Input Voltage: 3V~40V

Switching Frequency: N/A

Channel Count: 1

Output Voltage: N/A

Output Current: 1A

Dimming Mode: PWM, Analog

Features: OTP (Over-Temperature Protection)

AC Input Voltage: N/A

Topology: Linear

Operating Temperature: -40℃~+125℃

Power MOSFET: Internal

Constant Current Accuracy: ±3%

HLD3350AL

Output Polarity: Positive

Input Voltage Rating: 50V

Fixed Output Voltage: 3.3V

Output Current: 250mA

PSRR: N/A

Dropout Voltage: 530mV @ 100mA

Quiescent Current (Iq): 2μA

Noise: N/A

Features: Short-Circuit Protection, Thermal Shutdown

Operating Temperature: -40℃~+85℃

Output Type: Fixed

Output Channel Count: 1

Hi9300E

Topology: Buck

Input Voltage Range: 8V~120V

Output Voltage Range: 900mV~36V

Output Current: 25A

Switching Frequency: 70kHz / 300kHz

Operating Temperature: -40℃~+130℃

Synchronous Rectification: Yes

Output Channel Count: 1

Quiescent Current (Iq): 800μA

Power MOSFET: External

Output Type: Adjustable

Features: Cycle-by-Cycle Current Limiting, Adjustable Soft Start, Over-Current Protection, EMI Spread Spectrum (Jitter Mode), Adjustable Current Limit, Hiccup Current Limit, Protection Latch

Hi7023H

Type: DC-DC

DC Input Voltage: 6.5V~75V

Switching Frequency: 1MHz

Channel Count: 1

Output Voltage: N/A

Output Current: 3A

Dimming Mode: PWM

Features: OTP (Over-Temperature Protection)

AC Input Voltage: N/A

Topology: Buck

Operating Temperature: -40℃~+125℃

Power MOSFET: Internal

Constant Current Accuracy: ±3%

Hi7012

Type: DC-DC

DC Input Voltage: 5V~60V

Switching Frequency: 30kHz~1MHz

Channel Count: 1

Output Voltage: N/A

Output Current: 2.5A

Dimming Mode: PWM

Features: OTP (Over-Temperature Protection)

AC Input Voltage: N/A

Topology: Buck

Operating Temperature: -40℃~+125℃

Power MOSFET: Internal

Constant Current Accuracy: ±3%

HI8001

Topology: Boost

Input Voltage Range: 2.7V~40V

Output Voltage: N/A

Output Current: 1.5A

Switching Frequency: 130kHz / 260kHz

Operating Temperature: -40℃~+125℃

Synchronous Rectification: N/A

Output Channel Count: 1

Quiescent Current (Iq): 2mA

Power MOSFET: Internal

Output Type: Adjustable

Features: Light Load High Efficiency Mode, Built-in LDO Regulator, Cycle-by-Cycle Current Limiting, Adjustable Soft Start

Hi9214

Topology: Buck

Input Voltage Range: 5V~65V

Output Voltage Range: 810mV~61.75V

Output Current: 1A

Switching Frequency: 450kHz

Operating Temperature: -40℃~+150℃

Synchronous Rectification: No

Output Channel Count: 1

Quiescent Current (Iq): 1mA

Power MOSFET: Internal

Output Type: Adjustable

Features: Cycle-by-Cycle Current Limiting, Over-Current Protection

HLD5050AL (Duplicate)

Output Polarity: Positive

Input Voltage Rating: 50V

Fixed Output Voltage: 5V

Output Current: 250mA

PSRR: N/A

Dropout Voltage: 550mV @ 100mA

Quiescent Current (Iq): 2μA

Noise: N/A

Features: Short-Circuit Protection, Thermal Shutdown

Operating Temperature: -40℃~+125℃

Output Type: Fixed

Output Channel Count: 1
